ROTARY SWITCH
-
旋轉開關
1101 Rotary switch
SPECIFICATION:RATING : 3A 125VAC, 1.5A 250VAC
CIRCUIT : FROM 1P1T TO 1P4T
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
-
旋轉開關
1107 Rotary switch
SPECIFICATION:
RATING :
5A 125VAC, 2.5A 250VAC (UL,CUL)
0.5A 125VDC
CIRCUIT : FROM 1P1T TO 1P5T
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
ELECTRICAL LIFE : 6,000 CYCLES
-
旋轉開關
2108E Rotary switch
SPECIFICATION:
RATING :
20.2A 125/250VAC
30.2A 125/250VAC
1HP/2HP 125/250VAC
1/3HP,8A 125/250VAC
8A, 25A, 125V/250VAC
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
ELECTRICAL LIFE : 6,000 CYCLES
-
旋轉開關
2121 Series Rotary switch
SPECIFICATION:
RATING :
16A 125/250VAC T105
16A 250V ~ T125
16(6)A 250V ~ T125
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : AC 1500V FOR 1 Min
ELECTRICAL LIFE : 10,000 CYCLES
-
旋轉開關
2134E Rotary switch
SPECIFICATION:
RATING :
20.2A 125/250VAC
30.2A 125/250VAC
1HP/2HP 125/250VAC
1/3HP,8A 125/250VAC
8A, 25A, 125V/250VAC
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
ELECTRICAL LIFE : 6,000 CYCLES
-
旋轉開關
2141B Rotary switch
SPECIFICATION:
RATING :
20.2A & 30.2A 125/250VAC
1HP/2HP 125/250VAC
1/3HP,8A 125/250VAC
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
ELECTRICAL LIFE : 6,000 CYCLES -
旋轉開關
2144B Rotary switch
SPECIFICATION:
RATING : 10.1A 125VAC (UL,CUL)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
-
旋轉開關
2145 Rotary switch
SPECIFICATION:RATING :
10A 125VAC, 6A 250VAC
16A 125/250VAC
DC12V 10A, DC24V 5A
DC12V 15A, DC24V 10A
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
-
旋轉開關
2146 Rotary switch
SPECIFICATION:
RATING :
25A 125VAC 1 1/4HP
25A 250VAC 2HP
21A 125/250VAC
6A 125/250VAC 1/4HP
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 30mΩ OR LESS
WITHSTAND VOLTAGE : AC 1000V FOR 1 Min
-
旋轉開關
8105 Series Rotary switch
SPECIFICATION:
RATING : 5A 250VAC, 16A 250VAC
CIRCUIT : FROM 1P1T TO 1P11T
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
